| Specification | |||
| Model | TS-EVC07-002C-001(S) | TS-EVC1 1-002C-001(S) | TS-EVC22-002C-001(S) |
| Electrical Properties | |||
| Voltage | 230V AC ±10% | 380V AC ±10% | 380V AC ±10% |
| Output Current | 32A | 16A | 32A |
| Frequency | 50/60Hz | 50/60Hz | 50/60HZ |
| Output Power | 7kw | 11kw | 22kw |
| Residual current protection | TypeB (AC 30mA+DC 6mA) | ||
| Design | |||
| Emergency Stop Button | Yes | ||
| Display | 5″ LCD touch screen | ||
| RFID Function | 5pcs cards | ||
| Charging Outlet | One charging socket (Type 2) /4.5M charging cable | ||
| Power incoming line | 0.7M | ||
| Housing Material | PCV0 for outdoor | ||
| Front Panel | PC | ||
| Installation Method | Wall-mount/Floor-stand | ||
| Network Gateway | Wifi | ||
| Communication Protocol | OCPP1.6(J-SON) | ||
| Safety Standard | EN IEC 61851-1:2019； IEC 61851-1:2017； EN IEC 61851-21-2:2021； EN IEC 61000-6-1:2019； EN IEC 61000-6-2:2019； EN IEC 61000-6-3:2021； EN IEC 61000-6-4:2019； ETSI EN 300 328 V2.2.2:2019； ETSI EN 300 330 V2.1.1:2017； ETSI EN 301 489-1 V2.2.3:2019； ETSI EN 301 489-3 V2.1.1:2019； ETSI EN 301 489-17 V3.2.4:2020； EN IEC 62311:2020 | ||
| Warranty | 2 years | ||
| Environmental Performance | |||
| Protection Level | IP65 | ||
| Working Altitude | V2000M | ||
| Application Site | Indoor/〇utdoor | ||
| Working temperature | -30C~+50C | ||
| Working humidity | 5%~95%, No condensation | ||
| Atmospheric pressure | 80kPa~101kPa | ||
| Packing Details | |||
| Product Size | 398*324*120mm | 398*324*100mm | 398*324*100mm |
| Product Weight | 10KG | 11KG | 12KG |
| Optional Config | |||
| Dynamic load balancing | RS485 meter or local junction box (optinal) | ||
| Energy Meter | MID certified | ||
| Network Gateway | Ethernet/4G | ||
Smart OCPP EV Wallbox
Modular design – Configurations can be added or subtracted according to your request, which is also simple and convenient to assemble and maintain to save your operating cost.
More secure – The charger uses MID certified meter to ensure accuracy and built-in RCD to secure safety. The charger also can includes type B RCD to make the charging safer.
Commercial charging Management – Remote control your charging station with OCPP Protocol.
Monitoring and reporting – Track and adjust power consumption
Economic – Select your energy tariff and let the system automatically work out the cheapest time to charge your EV
Dynamic load balancing – RS485 electric meter and local balance load junction box control, to realize the dynamic load balance
Local balancing centre loading controller – Max 30 pcs of devices working at the same time, Pro-Smart OCPP can achieve dynamic load balancing through local junction box, and a WiFi wireless model will be launched next
More durable – PC V0 material, capable of withstanding high temperature environments, fifireproof and heat-resistant
OCPP full function – Our wallbox has OCPP1 .6-J full functions, including core functions, smart charging, appointment, remote firmware upgrade, etc
